Moveable Electric Station Description

The COMLER High-Speed Mobile Power Station is a new generation of high-performance high-speed mobile power supply vehicle specially designed for users. It adopts a high-strength heavy-duty design, with a high-strength heavy-duty mechanical design for the overall frame. The main body is of a traction type structure, divided into two-wheel and four-wheel versions. The adjustable snake-shaped traction rod is suitable for various vehicles for convenient and flexible towing. The reliable safety disc brake system is equipped with guide wheels and four-point support. The box body adopts a smooth and streamlined design similar to a car, which is beautiful and elegant. The product design is safe and reasonable, in line with the GB/T2819-1995 national standard, and is suitable for rapid emergency power supply, field engineering construction, rescue, disaster relief, highways, railways, water conservancy, exploration and mining, oil depots and stations, communication, and other types of users. It is highly favored by a wide range of users.

The entire machine is equipped with COMLER full range of high-pressure common rail National Standard III engines, permanent magnet generators, LCD intelligent control system, high-temperature-resistant 50° radiator, heavy-duty high-strength mobile silent trailer. With superior overall design, production, and assembly, as well as a full-chain product range, it eliminates the drawbacks of assembled units. The service is more reliable, and the high-performance heavy-duty design is more suitable for industries with high-frequency usage. The prestigious international brand will provide customers with better services, continuously create value for customers, and contribute to promoting the overall technological development and progress of China's power industry.

移动75

移动150


Function and Advantages

1.Chassis advantages: The overall frame is designed with high-strength and heavy-load capabilities. The chassis is made of high-strength special profiles, which are rapidly cut by laser to prevent the profiles from annealing. This design fully complies with high-speed and high-strength driving requirements.

2.Advantage of towing: Adjustable snake-shaped towing bar (for vehicles under 120KW), suitable for towing various vehicles with ease and flexibility.

3. Speed advantage: The ordinary mobile power station has a speed of 15-25 kilometers per hour, while the COMLER mobile power station has a speed of 60-80 kilometers per hour. Advantage of towing: Adjustable snake-shaped towing bar (for vehicles under 120KW), suitable for towing various vehicles with ease and flexibility.

4. Advantages of ultra-low chassis: The trailer can perform towing and steering safely and flexibly. The frame crossbeam is made of cast steel, which is more sturdy. The overall chassis design is designed with an ultra-low distance from the ground, ensuring the stability of the trailer.

5.Shock absorption advantage: For engines under 120kw, advanced high-performance torsional shock absorption is adopted; for engines above 150kw, spring steel plate shock absorption is used. This makes the trailer more stable when moving at high speeds or in the wild, and enhances its off-road performance.

6.Brake advantages: The emergency mobile power station adopts disc brakes, which have excellent braking performance and a high safety factor. It can quickly brake during high-speed movement or in emergency situations. The braking is sensitive and can be driven by any vehicle. When the front vehicle brakes, the rear vehicle can automatically brake in an emergency (below 120kW). The power vehicle can use parking brakes when stopping, and the parking brake will firmly hold the brake disc to prevent the vehicle from skidding.

For power exceeding 150KW, four-wheel pneumatic drum brakes are adopted. The brakes are highly sensitive and suitable for continuous braking at high speeds and under heavy loads, as well as in complex road conditions. The high-performance braking system is even safer and more reliable.

7.Tire configuration: For vehicles with power below 300KW, high-speed vacuum explosion-proof tires are used; for those with power ranging from 400KW to 600KW, heavy-duty steel wire tires are adopted. The high-strength wheel hubs have strong durability. Each trailer is equipped with a spare tire, ensuring safety and reliability during movement.

8. Advantages in steering: All mobile power stations are equipped with a guiding support wheel (for units below 120kW). For units above 150kW, a turntable is used for steering. This provides convenient and flexible steering. The trailers are all equipped with an automatic steering warning system and have quick plug-in connectors to the front vehicle, enhancing steering safety.

9.Heavy-duty advantages: The mobile power station is designed with heavy-duty and high-strength features. When the power station is in motion, it is capable of smoothly passing through various complex road conditions. During use, each mobile power station is equipped with four manual mechanical support legs, ensuring the stability of the power station during operation.

移动250

移动400




10.Door and window advantages: Maintenance doors are installed on both sides of the box, facilitating the operation and maintenance by the operators. High-performance carbon steel door locks are adopted, making the opening more convenient and enhancing the overall weather resistance performance of the machine.

11.Advantages of the trailer body: The trailer machine room body is made of galvanized sheet coated with plastic. The body will not rust for ten years. It has heat preservation and rainproof functions. The electric start is applicable in an ambient temperature range of -30℃ to 42℃, making it suitable for emergency use.

12. Silent mode advantage: The cabinet is manufactured in accordance with the requirements of silent units, which helps prevent disturbance to the surrounding area and is more environmentally friendly.

13. Advantages of cable dragging: The power station can be equipped with a manual winding assist device / 30-50 meters of cable, quick-connectors, which provide convenience for long-distance power supply of mobile power stations and rapid connection of cables.

14. Intelligent Interconnection Advantages: Deep integration of humans and the crew, using mobile phone apps to manage the crew, Internet + generator, with the excellent combination of Internet technology and generators (domestic), achieving remote management and uninterrupted service for the generators, enabling them to operate at a higher efficiency. Significantly reducing manpower, material resources, and financial costs, continuously creating value for customers.
